1/8 DIN Thermocouple Panel Meter With Large Color Display

Original price was: $356.00.Current price is: $95.99.

Big Bright LED Display
Peak Recall
Dual Programmable Setpoints
Optional Analog Output

Display Type

Alarm Output

Retransmission Output

Supply Voltage Type

Additonal Features

Clear

SKU: DP25B-TC Categories: Control & Monitoring, Meters, Temperature Meters Tag: Omega Engineering

100% Quality Satisfaction
Uncompromising quality, every time.
Quality You Can Trust
Your questions, our prompt answers.

The OMEGA DP25B series Digital Panel Meters feature the biggest brightest display of any 1/8 DIN panel meter. The user can select the display color: RED, AMBER, or GREEN.

PANEL METERS with Relays and Analog Output
The popular DP25B series are accurate, economical, and easy to program. The DP25B series feature a big bright four digit display plus optional dual 5 amp Form C (SPDT) relays and a choice of isolated or non-isolated analog output. The scalable 0-10 Vdc, 0-20mA, or 4-20 mA analog output can be used as a retransmission of the display value or as a proportional control output as required. The microprocessor based DP25B series includes instruments for Thermocouple, Process (DC voltage and current), and Strain Gage.

THERMOCOUPLE METER/CONTROLLER
The OMEGA DP25B-TC accepts type J, K, T and DIN J thermocouples. Standard features include resolution of 0.1° or 1.0°, °F or °C indication. Factory default setup is type K thermocouple input in °F.

The DP25B-RTD series has been discontinued. Please see the DPPt series as a possible alternative or contact sales engineering department.

SPECIFICATIONS
Input: Thermocouples types, J, K, T, and J DIN
Relay Outputs: 2 Form C (SPDT) relays, rated 5 Amp 250 Vac; programmable for active high/low alarms with latching/non-latching relays (optional).
Relay Hysteresis: programmable from 0 to 9999
Analog Output: Scalable 0-10 Vdc or 4-20 mA (optional).
Accuracy: ±0.50°C after 30 min. warm-up
Temperature Coefficient: ±50 PPM/°C
Read Rate: 3/sec
Step Response: 2 seconds
Isolation: Dielectric strength to 2500V transient per 3mm spacing based on EN 61010 for 260 Vrms or DC.
NMR: 60 dB
CMR: 120 dB
Input Resistance: 100 Mohms
Operating Temperature: 0 to 50°C (32 to 123°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Display: 4-digit, LED 9-segment, 21 mm (0.83″), (Red, Green, Amber)
Dimensions: 48 H x 96 W x 152 D mm (1.89″ x 3.78″ x 6.0″)
Panel Cutout: 45 x 92 W mm (1.772″ x 3.622″)
AC Power Unit:
Power: 115 Vac or 230 Vac ±10%; 50-60 Hz, 8 watts max.
DC Power Unit:
Power: 12-32 Vdc; 7 watts max.

Display Type	3.5 Digit Single Display, 4 Digit Single Display
Alarm Output	None, 2 Relays, 1 Relay
Retransmission Output	None, Analog Current/Voltage
Supply Voltage Type	AC, DC
Additonal Features	None, 230 Vac, 230 Vac, Isolated Retrans, Temperature, Process and Strain
Measurement Type	Temperature
Input Type	Thermocouple
Number of Inputs	1
Form Factor	1/8 DIN
Max Sampling Rate	3 Hz
