2 Channel 7 Thermocouple Types Datalogger Water/Splash Proof

Description

The OMEGA™ HH500RA is a low cost, feature-packed, portable, digital thermometer that measures K, J, R, S, T, E and N thermocouples. The unit has datalogging capacity in the save mode of 128 samples with real-time data and in the datalogging mode of 16 sets, with a maximum data capacity of 1024 records. Easy to use set-up instructions allow the user to measure a broad range of T/Cs, MAX/MIN, AVG, REL, Hold Function, T1/T2.

SPECIFICATIONS
Temperature Range:
    K Type: (0.1°, 1° for above 2000°F) -200 to 1372°C (-328 to 2501°F)
    J Type: (0.1°, 1° for above 2000°F) -210 to 1200°C (-346 to 2192°F)
    T Type: (0.1°) -200 to 400°C (-328 to 752°F)
    E Type: (0.1°) -210 to 1000°C (-346 to 1832°F)
    R Type: (1°) 0 to 1767°C (32 to 3212°F)
    S Type: (1°) 0 to 1767°C (32 to 3212°F)
    N Type: (0.1°, 1° for above 2000°F) -50 to 1300°C (-58 to 2372°F)
According to temperature standard ITS-90
Accuracy:
    K/J/T/E Type:
    ±(0.05% rdg + 0.3°C) on -50 to 1370°C
    ±(0.05% rdg + 0.7°C) on -50 to -210°C
    ±(0.05% rdg + 0.6°F) on -58 to 2501°F
    ±(0.05% rdg + 1.4°F) on -58 to -346°F
    N Type:
    ±(0.05% rdg + 0.8°C) on -50 to 0°C
    ±(0.05% rdg + 0.4°C) on 0 to 1300°C
    ±(0.05% rdg + 1.6°F) on -58 to 32°F
    ±(0.05% rdg + 0.8°F) on 32 to 2372°F
    R/S Type:
    ±(0.05% rdg + 2°C) on 0 to 1767°C
    ±(0.05% rdg + 4°F) on 32 to 3212°F
Resolution: 0.1°C/1°C (0.1°F/1°F)
Power: 9 V battery (included)
Datalogger Capacity:
    Save Data: 128 samples with time stamp
    Datalogger: 1024 data capacity(interval 1 sec to 23:59:59)
