High Temperature Bayonet Style Thermocouple Probes

Original price was: $72.98.Current price is: $51.09.

High-Temperature Design
Wide Variety of Immersion Lengths, Styles and Mounting Arrangements Available
Fast Delivery on Standard Configurations
304 SS Sheath, Solid 4.7 mm (3.16′) Diameter Probe

Thermocouple Type

Process Temperature Max

Process Temperature Range

Junction Type

Probe Diameter

Probe Length

Cable Length

Termination Connection Type

Additional Feature

Clear

SKU: BTH-000-J-3 1/2-60-2-UNG Categories: Probes with Lead Wires, Temperature Probes Tag: Omega Engineering

100% Quality Satisfaction
Uncompromising quality, every time.
Quality You Can Trust
Your questions, our prompt answers.

OMEGA’s rugged Spring-Loaded Bayonet Style Thermocouples are ideally suited for measuring plastic processing machinery temperatures at the crosshead, die, and barrel. With OMEGA’s pipe clamp adapter, the Bayonet type can be used to measure pipewall and bearing temperatures. This style provides a quick means to connect and disconnect te sensor. The maximum length for armored cable is 40 feet (5 feet is standard). Dual elements are available. The standard termination is Style 1 or Style 2. Style 3 is available upon special request. Probes with 45°bends are also available. Consult Sales Department for availability.

Examples of pricing for popular models is referenced in the “To Order” box. Use the “Part Number Builder” below to get pricing for other available models.

View the Thermocouple Accuracy and Color Code charts

Thermocouple Type	J, E, K, T
Process Temperature Max	620, 730, 1150, 370, 480
Process Temperature Range	0 to 620°C (32 to 1150°F), 0 to 730°C (32 to 1350°F), 0 to 1150°C (32 to 2100°F), 0 to 370°C (32 to 700°F), 0 to 480°C (32 to 900°F)
Junction Type	Ungrounded, Grounded
Probe Diameter	0.187 in, 3/16 in
Probe Length	3.5 in, 2.25 in, 1.625 in, 4.5 in, 4 in, 12 in, 10 in, 2.75 in, 3 in, 5.5 in, 5 in, 6 in, 6.625 in, 13 in, 2 1/2 in, 2.5 in, 2 in, 6.5 in
Cable Length	60 in, 120 in, 78 in
Termination Connection Type	Standard Connector, Spade Lugs, Standard Male Connector
Additional Feature	Straight Probe, Straight Probe Dual Elements, 90 Degree Angle Probe, 90 Degree Angle Probe Dual Elements, Immersion Probe
Category	Thermocouple
Process Temperature Unit	°C
Process Temperature Min	0
Sensor Application	Immersion Probe
Process Connection Size	Bayonet Style Locking Fitting
Sheath Material	304 Stainless Steel
Cable Insulation	Fiberglass with Armored Cable
