Industrial Pressure Switch For Harsh Environments With 2 Outputs

Original price was: $385.00.Current price is: $97.99.

All-Stainless NEMA-4X Case Resists Industrial Corrosion
Designed for Tough Industrial Applications with Long Life UL and CSA Rated Switches
Ranges from 5 inH₂O to 3000 psi
Easy to Adjust with Internal Reference Scale

Pressure Range

Deadband Range

Clear

SKU: PSW-370 Categories: Pressure Measurement, Pressure Switches Tag: Omega Engineering

100% Quality Satisfaction
Uncompromising quality, every time.
Quality You Can Trust
Your questions, our prompt answers.

SPECIFICATIONS
Electrical Rating:
   15 A: 125/250/480 Vac
   0.5 A: 125 Vdc
   0.25 A: 250 Vdc
Switch Output: Two SPDT switches can be wired for Normally Open or Normally Closed operation
Setpoint Repeatability: ±1% range
Ambient/Storage Temperature: -29 to 66°C (-20 to 150°F)
Setpoint: Typically shifts ±1% of range per 28°C (50°F)
Electrical Connections: 3/4 NPSM, 316 SS fitting
Pressure Connections: 1/4 NPT Female, 304 SS
Wetted Parts:
   InH₂O and 1000/3000 psi ranges: PTFE and stainless steel
   15 psi to 600 psi ranges: stainless steel.
Enclosure: Gasketed 316 SS, NEMA-4X rated

Pressure Range	5 to 30 inH2O, 22 to 150 inH2O, 3 to 15 psi, 6 to 30 psi, 20 to 100 psi, 40 to 200 psi, 80 to 400 psi, 120 to 600 psi, 150 to 1,000 psi, 450 to 3,000 psi
Deadband Range	2.5 to 5.9 inH2O, 8.4 to 19.2 inH2O, 2.4 to 3.6 psi, 2.4 to 6.8 psi, 85 to 15.3 psi, 17 to 34 psi, 37.4 to 71.4 psi, 37.4 to 119 psi, 84 to 216 psi, 301 to 418 psi
Switch Type	(2) 15 A SPDT
Pressure Type	Gauge
Pressure Port Size	1/4"
Pressure Port Type	NPT Female
Deadband	Fixed
Features	Stainless NEMA 4X, IP66 Enclosure
