Silicon-on-Sapphire Pressure Transducers
Original price was: $333.00.$96.99Current price is: $96.99.
- Silicon on Sapphire Construction
- Titanium Wetted Parts for Media Compatibility
- 0.25% Accuracy
- 100 mV Bridge Output is Compatible with Most Strain Gage Instrumentation
- 100% Quality Satisfaction
- Uncompromising quality, every time.
- Quality You Can Trust
- Your questions, our prompt answers.
OMEGA’s PX4201 Series Transmitters bring state-of-the-art Silicon-on-Sapphire (SOS) sensor technology to the industrial arena. SOS construction uses very stabile solid state silicon strain gages on a Sapphire carrier which is glass bonded to a titanium diaphragm. This combination provides a very durable transducer which has excellent stability over a wide temperature range. Additionally, the all titanium wetted parts provide maximum corrosion resistance to harsh industrial chemicals.
SPECIFICATIONS
Excitation: 10 Vdc @ 5 mA (15 Vdc max)
Output: 100 mV ratiometric
Bridge Resistance: 1500Ω ±30%
Accuracy: ±0.25% FS includes linearity, and hysteresis
Long Term Stability: ±0.2% (6 months)
Repeatability: ±0.1% FS
Long Term Stability: ± 0.2% FS (1 year)
Media Temperature: -50 to 120°C (-58 to 248°F)
Ambient Temperature: -40 to 80°C (-40 to 175°F)
Thermal Zero Effect: <±0.016% FS/°F
Thermal Span Effect: <±0.016% FS/°F
Humidity: 95% RH non-cond.
Maximum Overpressure: 200% FS
Sensor: Silicon on Sapphire
Wetted Parts: Titanium
Case Material: Stainless Steel, IP65
Pressure Port: ¼ NPT male
Electrical Connection: Din 43650 Plug with Mating Connector Supplied
Response Time: 0.2 ms, 63%
Weight: 90 g (3.2 oz)
| Pressure Range | 0 to 100 psi, 0 to 5 psi, 0 to 10 psi, 0 to 15 psi, 0 to 30 psi, 0 to 60 psi, 0 to 150 psi, 0 to 1500 psi, 0 to 1000 psi, 0 to 200 psi, 0 to 2.5 bar, 0 to 2,000 psi, 0 to 300 psi, 0 to -30 inHg, 0 to 3,000 psi, 0 to 600 psi, 0 to 6,000 psi |
|---|---|
| Pressure Type | Gauge, Vacuum |
| Output Signal | Current, Ratiometric mV/V, Voltage |
| Electrical output | 4 to 20 mA, 10 mV/V, 0 to 5 Vdc |
| Accuracy Class | 0.1% to 0.25% |
| Accuracy Value(compensated range) | ±0.25% |
| Pressure Port Size | 1/4" |
| Pressure Port Type | NPT Male |
| Connection/Termination | DIN 43650 A |
| Operating Temperature Range | -40 to 80 °C (-40 to 176 °F) |
| Additional Features | Titanium Wetted Parts |
