WE01-Series
Original price was: $375.00.$95.99Current price is: $95.99.
- Vented ball to reduce operating torque
- Weatherproof electric actuators
- Double acting or spring return pneumatic actuators
- Full port design reduces the pressure drop across the valve
- Ideal for quick bubble tight shut-off
- Blowout proof stem
- 100% Quality Satisfaction
- Uncompromising quality, every time.
- Quality You Can Trust
- Your questions, our prompt answers.
Dwyer Instruments is now a DwyerOmega product brand.
The Series WE01 incorporates a full port 2-piece SS ball valve for great flow rates with minimal pressure drop. The valve features a blowout proof stem for added safety, reinforced PTFE seats and seals for longer life, and a 316 SS (ASTM CF8M) ball for better performance. Actuators are direct mounted creating a compact assembly for tight spaces.
| Size | 3" NPT, 1/2" NPT, 3/4" NPT, 1" NPT, 1 1/4" NPT, 1 1/2" NPT, 2" NPT, 2 1/2" NPT |
|---|---|
| Actuator Type | Electric 2 Position, Pneumatic DA, Lever operated, Electric Modulating, Pneumatic SR |
| Actuator Supply Pressure | None, 40 to 115 psi (2.7 to 7.9 bar), 80 psi (5.5 bar), 81 psi (5.5 bar), 82 psi (5.5 bar), 83 psi (5.5 bar), 84 psi (5.5 bar), 85 psi (5.5 bar), 86 psi (5.5 bar), 87 psi (5.5 bar) |
| Air Connections | None, 1/8" female NPT, 1/4" female NPT |
| Power Requirements | 24 VDC, None, 110 VAC |
| Electrical Connection | 1/2" NPT, None |
| Enclosure Rating | NEMA 4X (IP67), None |
| Actuator Temperature Rating | -22 to 140F (-30 to 60C), -40 to 176F (-40 to 80C), None |
| Housing Material | Powder coated aluminum, Anodized Aluminum body and epoxy coated aluminum end caps, None |
| Media Type | Compatible liquids and gases |
| WETTED MATERIALS | Body and ball 316 SS (CF8M) Stem 316 SS Seat RTFE/PTFE Seal, washer & packing PTFE |
| Valve Pressure Limit | 28" Hg to 1000 psi (-0.7 to 69 bar) up to 250F |
| Valve Temperature Limit | -20 to 392F (-29 to 200C) |
